Automotive Seals Measurements

Dynamic car seals used in automotive industry are complex in both design and function as they not only need to maximize the seal between fixed and movable parts but also have to compensate for the manufacturing tolerances of various body parts. This necessitates accurate measurement of its dimensions to ensure that these seals can not only perform their designated function effectively but also have a long life. Image Based Field of View Measurement systems can automatically compare seal data against their CAD data to produce an operator free Pass/Fail result.

Deviations from normal are automatically measured and displayed to identify out-of-tolerance areas. The measuring system not only deals with part distortion but also supports both uniform and variable tolerances. The reports can be customised to include measurements, statistics and images. The accurate repeatable and operator independent results are instantly available.
