An Image-based Measuring System , also known as an Optical Measuring System, is a non-contact measuring technique that uses digital images to obtain precise measurements of objects or surfaces. The basic principle of this system is to use imaging optics to project an object onto a digital image sensor and then use image analysis algorithms to extract the relevant measurement information from the captured image.

Our Products

Cable Genie

Cable Genie
Part Genie

Part Genie
Rubber Seal Genie

Rubber Seal Genie

Spring Genie

Spring Genie

Get A Quote

Principle Of Image Based Measurement Systems

An Image-based Measuring System’s main components include a digital camera, image acquisition hardware, and image analysis software. The camera captures the image of the object and transfers it to the computer, where the image analysis software processes it to extract the relevant measurement information. The software then uses various algorithms, such as edge detection, pattern recognition, and dimensioning tools, to perform the measurements.

Applications of Image based Measuring Systems are vast and can be found in various industries including manufacturing, engineering, quality control, metrology, and medical imaging. Some of the common applications of these systems are:
1. Dimensional Inspection: Image based Measuring Systems can be used to measure the dimensions of objects, such as length, width, height, and diameter, with high accuracy and repeatability.
2. Surface Inspection: These systems can be used to inspect the surface quality of objects, such as cracks, chips, and defects, by analyzing the captured images.
3. Assembly Inspection: In assembly lines, Image based Measuring Systems can be used to inspect the assembled components to ensure their proper fit and alignment.
4. Medical Imaging: In the medical field, Image based Measuring Systems can be used to measure the size and shape of organs, tissues, and bones for diagnostic purposes.

In conclusion, Image based Measuring Systems have proven to be a versatile and efficient tool for a wide range of applications, providing accurate and reliable measurements in a non-contact, fast and cost-effective manner.

Frequently Asked Questions

An image measurement system is used to accurately quantify and analyse characteristics or dimensions of objects within images. It helps in quality control in manufacturing, medical imaging analysis, and scientific research by providing precise measurements and data from visual information.
To identify verified image measurement machine manufacturers, look for certifications like ISO, check customer reviews, examine company history and industry reputation, and verify partnerships with recognized organizations or suppliers in the field.
The price of an image measurement system in India can vary widely based on its features and quality. It can range from 5-80 lakhs, depending on the specifications and brand.
To buy image measurement system from a genuine manufacturer there are many suppliers and traders in the industry which provide cheap low- quality products. But we always recommend the customer purchase measuring instruments which can adhere to ISO, JIs standards etc. These instruments must be purchased only from a genuine manufacturer which provides prompt service and has a dedicated service team.
To receive a quote from Sipcon Technologies, just fill out the form with your requirements. Their sales team will call you back. You can also reach them at +91 82229 29966 or email info@sipconinstrument.com anytime.
