Field of View Measurement Systems

These are specially designed systems that can instantly measure small flat parts.

Working Principle

• The system uses a ‘flat-field’ telecentric lens coupled to a high resolution video camera to provide a distortion free, flat image across the field of view.
• The part program is created before hand that directs the algorithm for part specific measurements on the captured image. The same program is used for similar parts.
• The part program is created before hand that directs the algorithm for part specific measurements on the captured image. The same program is used for similar parts.
• For measurements the part is kept on the stage. The inspect button captures the image and the measure button displays the results instantly. Over 100+ dimensions are measured in one second.



Benefits

These systems provide multiple benefits that add real value to the quality assurance processes.

• Minimal Errors, more preciseness in the measured results
• Better accuracy owing to automated operation
• Reduced measurement time. From several minutes to one second.

Part Quickie

Part Quickie is a Field of View Measurement System that can instantly measure 2D dimensions of small flat parts for quality assurance. Depending on the type of part and the measurements required, one can choose from the following three models: Horizontal Part Quickie, Vertical Part Quickie, Dual Part Quickie.

Features

• 1/100 Pixel Image Processing
• Integrated Statistical Process Control
• Easy Part Programming
• Auto-Alignment
• DXF Overlay (CAD Interface)
• Color Coded Tolerances
• Color Measurement
• Dual Camera
• Customizable report format with color coded Pass/Fail results.

Why choose Sipcon Part Quickie?

• Market Proven Product launched in 2014.
• 25+ Satisfied Customers Worldwide (March 2019)
• Maintenance free operation
• Best-in-class accuracy and precision
• Traceability to Internationally recognised Standards.
• A Product from Sipcon, providing industrial metrology systems since 1971.
